This alarm evaluates the unbalance of the phase to phase voltages, i.e. the
difference between highest and lowest phase to phase voltage at any given time.
The following setpoints are related to it:
Voltage Unbalance BOC (page 247) adjusts the maximum allowed
difference between the highest and lowest phase voltage at any given time.
Voltage Unbalance BOC Delay (page 248) adjusts the alarm delay.
6 back to List of alarms level 2
Alarm Type BOC
Alarmlist message BOC Gen Voltage Unbalance ph-n
Alarm evaluated Generator excited only
Related applications AMF, MRS
Description
This alarm evaluates the unbalance of the phase voltages, i.e. the difference
between highest and lowest phase voltage at any given time. The following
setpoints are related to it:
Voltage Unbalance BOC (page 247) adjusts the maximum allowed
difference between the highest and lowest phase voltage at any given time.
Voltage Unbalance BOC Delay (page 248) adjusts the alarm delay.
BOC Gen Voltage Unbalance Ph-N
6 back to List of alarms level 2
Alarm Type Shutdown
Alarmlist message Sd + Name of binary input
Alarm evaluated Generator excited only
Related applications AMF, MRS
Description
The overcurrent alarm is based on IDMT principle. The reaction time of an IDMT
alarm is not fixed, but depends on how much is the protected value (generator
current in this case) above the limit (Nominal Current (page 191)). The higher is
the overcurrent, the shorter the reaction time will be. All generator phases are
evaluated.
The behaviour of the overcurrent alarm is adjusted by the following setpoints:
IDMT Overcurrent Delay (page 244) defines the reaction time of the
protection when the current is twice the amount of nominal value.
Nominal Current (page 191) set the nominal current level, where the
alarm starts to be evaluated. The reaction time is infinite at this point.
BOCOvercurrent IDMT
