InteliLite
NT
– AMF20/25, SW version 1.2, ©ComAp – March 2008 25
IL-NT-AMF-Reference Guide1.2.pdf
Set to: Alarm
Config: selection between Analog, Binary Tri-state input.
“Analog” – resistor sensor is connected to Analog input.
“Binary” – open/close contact is connected between Analog input and COM terminal of Analog inputs.
Analog input detects only open/close state.
“Tri-state” – open/close contact is connected parallel to one of two serial resistors between Analog
input and COM terminal of Analog inputs.
Set to: Analog
Dim: Physical dimension of measured value (°C, %, Bar, ..) Maximal dimension length is three
characters.
Set to: Bar
Contact type: selection of polarity only when analog input is configured as Binary or Tri-state. When
is analog input configured as analog this setting has no sense.
„NC“ – polarity of binary or tri-state input
„NO“ – polarity of binary or tri-state input
Sensor: selection of sensor characteristic
„Unused input“ - when Analog input is not used. On the InteliLite screen is displayed „####“ value, no
alarm is detected.
„VDO 10 Bar“ – VDO pressure sensor
„VDO 40-120 °C“ – VDO temperature sensor
„VDO level %“ – VDO level sensor
Set to: VDO 10 Bar
Decimals: setting of number of decimal points of measured value.
„0“ - e.g. 360 kPa, 100%, 50
°C
„1“ – e.g. 3.6 Bar
„2“- e.g. 0.36 MPa
„3“ - e.g. 0.366 MPa
Set to: 1
When Analog input configuration is finished set the setpoints
AI1 Wrn, AI1 Sd, AI1 Del in Engine
Protect
group.
Each Analog input has separate triplet of setpoints:
Wrn level, Sd level, AI del. Names of these
setpoints are fix defined
Number of decimal points of
Wrn level and Sd level is the same as the configured number of
decimal points of measured value.
