Emergency MAN
If the input is activated the controller behaves like when switched to OFF Mode. Opens all binary
outputs. There is one exception – STOP SOLENOID doesn’t activate on this transition.
Detection of "running" engine and subsequent alarm message "Sd Stop Fail" is blocked.
The controller shows “EmergMan” state and the engine can not be started.
Generator current and power measurement is active in this mode, regardless of the actual state of the
engine.
After the input is open again, the controller recovers to previous state and behaves according to the
actual situation .
Function is active in any controller mode.
Start Button
Binary input has the same function as Start Button on the InteliLite front panel. It is active in MAN
mode only.
Stop Button
Binary input has the same function as Stop Button on the InteliLite front panel. It is active in MAN
Mode only.
Hint
:
Changed function of Stop Button. After the first pressing from running state, there is a standard delay
and controller change state to cooling. After holding the button down for 2 seconds controller goes to
stop state. The same holds true for BI “Stop Button”.
FaultResButton
Binary input has the same function as Fault Reset button on the InteliLite front panel.
HornResButton
Binary input has the same function as Horn reset button on the InteliLite front panel.
GCB Button
Binary input has the same function as GCB button on the InteliLite front panel. It is active in MAN
mode only.
MCB Button
Binary input has the same function as MCB button on the InteliLite front panel. It is active in MAN
mode only.
MainsFailBlock
If the input is closed, the automatic start of the gen-set at Mains failure is blocked. In case of running
gen-set the GCB is opened, gen-set goes to Cooling procedure and stops.
The input simulates healthy Mains.
