CAN J1939 interface
Following values can be received from Engine Control Unit via CAN bus instead of measuring on IL-
NT terminals when J1939 interface is enabled.
Value Value is received from
J1939 enabled J1939 disabled
RPM ECU IL-NT – RPM terminals
Oil pressure ECU or IL-NT AI1 IL-NT AI1 terminals
Water temperature ECU or IL-NT AI2 IL-NT AI2 terminals
Fuel level ECU or IL-NT AI3 IL-NT AI3 terminals
Use LiteEdit 3.0 to enable/disable J1939 interface and to configure IL-NT analog inputs.
Hint
:
RPM reading is automatically switched to pickup or generator voltage measuring (depends on Basic
Settings: Gear Teeth value) if J1939 fails.
