– AMF20/25, SW version 1.2, ©ComAp – March 2008 74
IL-NT-AMF-Reference Guide1.2.pdf
Communication object vs. Register
All the data intended for communication has its representation as communication objects in the
controller. The communication object is represented by the n-byte array in the controller memory and
identified by the unique 16-bit communication object number. The register, according to Modbus
communication protocol, represents a two-byte data and in communication functions is referenced by
16-bit register address. Further in the description of communication functions
the communication
object number will always be used as a register address
and length of the communication object
will be expressed by number of registers.
Just one communication object can be read or written
by one communication function.
Hint
:
To obtain communication object numbers it is possible to download the actual controller description
on-line from controller or from (ail) archive and use “export data” function from LiteEdit software.
Communication object list (exported from default IL-NT-AMF25 archive)
Setpoints of AMF25:
Name Firmware ver. Application Date App. ver. Ser. num. Filename
IL-NT
IL-NT-1.2.1
R:13.03.2008 AMF25 13.3.2008 1,2 12345678
IL-NT-AMF25-
1.2.1.AIL
Group Name Value Dimension Password Com. obj. Low limit High
limit
Data type
Basic Settings Gen-set Name IL-NT No 8637 Short string
Basic Settings Nominal Power 200 kW No 8276 1 32000 Unsigned 16
Basic Settings Nomin Current 350 A No 8275 1 10000 Unsigned 16
Basic Settings CT Ratio 2000 /5A No 8274 1 5000 Unsigned 16
Basic Settings PT Ratio 1,0 /1 No 9579 0,1 500,0 Unsigned 16
Basic Settings Vm PT Ratio 1,0 V/V No 9580 0,1 500,0 Unsigned 16
Basic Settings Nominal Volts 231 V No 8277 80 20000 Unsigned 16
Basic Settings Nominal Freq 50 Hz No 8278 45 65 Unsigned 16
Basic Settings Gear Teeth 120 No 8252 0 500 Unsigned 16
Basic Settings Nominal RPM 1500 RPM No 8253 100 4000 Unsigned 16
Basic Settings ControllerMode OFF No
8315 String list
Basic Settings FltResGoToMAN DISABLED No 9983 String list
Basic Settings ControllerAddr 1 Yes 24537 1 32 Unsigned 8
Basic Settings COM1 Mode COMAP Yes 24522 String list
Engine Params Starting RPM 25 % No 8254 5 50 Unsigned 8
Engine Params Starting Oil P 4,5 Bar No 9681 0,0 10,0 Integer 16
Engine Params Prestart Time 2 s No 8394 0 600 Unsigned 16
Engine Params MaxCrank Time 5 s No 8256 1 60 Unsigned 8
Engine Params CrnkFail Pause 8 s No 8257 5 60 Unsigned 8
Engine Params Crank Attempts 3 No 8255 1 10 Unsigned 8
Engine Params Idle Time 12 s No 9097 0 600 Unsigned 16
Engine Params Min Stab Time 2 s No 8259 1 10 Unsigned 16
Engine Params Max Stab Time 10 s No 8313 2 300 Unsigned 16
Engine Params Cooling Time 30 s No 8258 0 3600 Unsigned 16
Engine Params Stop Time 60 s
No 9815 0 240 Unsigned 16
