Compac C5000

31.
K-Factor Settings
GPi0
0000
Inputs Setting
0-0 Off
1-1 Channel Encoder
2-2 Channel Encoder
3-3 Channel Encoder
4-Switch Input
5-Remote Push to start
Output Settings
0-0 off
1-Volume (Litres/Kg’s)
2-Amount (Dollars)
Inputs Setting
0-1KHz
1-100Hz
2-200Hz
3-300Hz
4-400Hz
5-500Hz
6-600Hz
7-700Hz
8-800Hz
9-900Hz
a-1KHz
b-1.1KHz
C-1.2KHz
d-1.3KHz
C-1.4KHz
d-1.4KHz
Duty Cycle Setting
0-50%
1-10%
2-20%
3-30%
4-40%
5-50%
6-60%
7-70%
8-80%
9-90%
