- Make sure the Dip switches are the same as the board that was taken
out
- Turn the power to the dispenser back on.
- Check Dispenser operation. Checking Dispenser Operation.
NOTE: It should not be necessary to re-calibrate the dispenser unless a
pressure transducer or temperature probe needs to be replaced.
You can upgrade the dispenser software via USB Stick. Make sure the USB
stick is formatted as FAT32 and has the new dispenser software loaded on
it.
CAUTION: Before working on the dispenser electronics, take basic anti-
static precautions by wearing a wristband with an earth strap.
To record set-up data and tote information:
- Access the K-Factor board by opening the cover behind the main
display.
- Record all the set-up data by accessing the Parameter switch and the
K-Factor switch. Refer to Parameter Switch Settings and K-Factor
Switch Settings to obtain this information.
The following data is required from the Parameter switch :
▪ Dispenser pump price.
▪ Dispenser pump number.
▪ Dispenser Setting
▪ Software Program number, if you are upgrading to a new version.
The following data is required from the K-Factor switch:
▪ The K-Factor. There is a value for side A and side B in dual hose
dispensers.
▪ Configuration Code C.
▪ The Density Factor.
- Record the tote information by pressing the nozzle switch or start
button quickly five times
