Compac C5000 Service Manual

58.
Servicing
Bleed Valve Replacement
The bleed valve seldom gives problems and is not serviceable.
For a replacement valve and instructions if required, contact your Compac
service agent with your Model and Serial numbers.
Pressure Relief Valve Replacement
The pressure relief valve seldom gives problems and is not serviceable.
For a replacement valve and instructions if required, contact your Compac
service agent with your Model and Serial numbers.
KG100 Meter Replacement
To remove the meter:
- Shut off gas supply and degas the meter.
- Remove the inlet and outlet pipes from the old meter.
- Unscrew the SAE fittings from the meter inlet and outlet.
- Take note of the position and orientation of the communications plug
then unplug the meter cable from the K-Factor board and cut any cable
ties that hold it in place.
- Undo the four bolts that hold the meter on the dispenser frame.
- Remove the old meter.
To replace the meter:
- Secure the new meter to the dispenser frame using the four bolts.
- Plug the communications cable into the K-Factor board.
- Screw the SAE fittings into the meter inlet and outlet.
- Install the inlet and outlet pipes.
- Cable tie the communications cable to avoid pulling or damage to it.
- Load the meter ID into the K-Factor board
- Pressurise the meter and check for leaks.
- Calibrate the meter in accordance with the instructions in the
dispenser service manual.
