Compac C5000 Service Manual

40.
Servicing
Checking the Over-Pressure Operation
To check the operation of the Overfil Pressure cut off:
- Access the K-Factor switch on the K-Factor board.
- Obtain the overfill pressure settings 0pa
- Set the overfill pressure cut-off point to below the regulator pressure.
- Set the over pressure time to (deb) 01.0 or 1 second.
- For example, if the regulator pressure is 220 bar, then set the over-pressure
to 100 bar. An exact value is not required; just make sure that the value is
significantly lower than the regulator pressure.
- Start a fill. The dispenser should stop the fill after 1 second.
- Check the dispenser End of Sale indicator states that the fill has ended
because of over-pressure. End of Sale Indicators.
- Reset the over-pressure cut-off point to its original value.
Valve Adjuster (use 8 mm Hex Key)
