To install the new C5000 power supply:
- To install the new C5000 power supply, reverse the procedure above.
DANGER: Before replacing the lid on the flameproof box, make sure that the
O-ring is not damaged, and is seated properly in its groove. If the O-ring is
damaged and needs replacing, replace it with an O-ring of the same size and
specification (176 N70).
NOTE: It should not be necessary to recalibrate the dispenser. However, in
some locations, this may be legally required as per the Calibrate the Meter
section.
Before you start, obtain the following replacement parts
- Replacement C5000 Processor part number F-CP-C5K-PROCES
To remove the C5000 processor board:
- De-gas the dispenser.
- If possible, record all the set-up data by accessing the Parameter switch
and the K-Factor switch. The Software Set-Up and Upgrade section
contains details on obtaining this information.
- Switch off the power supply to the dispenser.
DANGER: Never remove any electrical components without first switching off
the power to the dispenser. Failure to turn off the power could result in an
electric shock.
- Remove the flameproof box lid to gain access to the C5000 Processor
board.
CAUTION: Take basic anti-static precautions by wearing a wristband with an
earth strap.
- Undo the screws that hold any coms or GPIO board into the C5000
processor board.
- Undo the screws that hold the C5000 processor board in the flameproof
box and remove the C5000 processor board.
To install the new C5000 processor board:
- Put the new C5000 board in place of the old one,
