Refuelling Hose Replacement
To remove the refuelling hose:
- De-gas the dispenser.
- Undo the JIC hose connection at the dispenser's outlet block.
- Undo the connection between the hose and the nozzle assembly.
To install the new refuelling hose:
- Attach the nozzle assembly to the new hose.
- Attach the new hose to the dispenser at the outlet block.
- Re-gas the dispenser and push the Start button to fill the new hose
assembly with gas.
- Check all hose connections for leaks by applying soapy water
mixture and looking for bubbles.
Power Supply Fuse Replacement
NOTE: There are three fuses used in the C5000 Flame proof box.
Before you start, make sure you have the following fuses with these ratings:
▪ F1 = 1.6 A
▪ F2,F3 = 0.5 A
▪ OR Compac fuse kit F-C5PWR-FKE
Fuse locations are displayed on the C5000 terminal board in the flameproof
box.
NOTE: Every new dispenser is supplied with one spare F1, F2 and F3 fuse,
located on the inside of the flameproof box lid.
