Compac C5000 Service Manual

72.
Servicing
Meter Replacement
Before you start, make sure you have:
- A new Compac meter F-D-MTR350-C5
To remove the Meter:
- De-gas the dispenser.
- Remove the tubing from the meter inlet and outlet.
- Unscrew the SAE fittings from the meter inlet and outlet.
- Unplug the meter connections to the K-Factor board.
- Undo the four bolts that hold the meter on the dispenser frame.
- Remove the meter.
To install the new meter:
- Reverse the steps above to install the new meter.
- Enter the Meter ID of the new meter into the K-Factor board
- Enter the new meter K-Factor into the K-Factor board.
- Check the dispenser calibration with the master meter. Refer:
Meter Calibration.
Unserviceable Parts List
The following parts are unserviceable on site and have to be returned to
Compac for servicing.
Part
Comment
KG Meter
The KG meter:
- Can have its firmware upgraded by approved service
agents.
- Can only be serviced by Compac.
- Has no set-up functions.
- Is self-characterising. The only function performed
in the set-up is setting the K- Factor on the K-Factor
Board and setting the Meter ID
C5000 Power Supply
C5000 CPU Board
Nozzles
Solenoid Stem
Replacing the solenoid stem seal requires special tooling.
