See below for information on serviced equipment.
Grade 10
Coalescing Filter
The coalescing filters are designed
to trap dirt, moisture, oil, and other
debris that may damage the valve
seals. A Grade 10 coalescing filter
will remove 95% of liquid aerosols
in the 0.3 to 0.6 micron range.
Compac
filter/check
valve
3/4” SAE female
inlet.
2 x 3/4” SAE
female outlets.
350 bar max.
The filter/check valve prevents
back-flow from the high storage to
the medium and low storage, and
from the medium storage to the
low storage.
The valve has a metal to metal seat
and should not leak or require
servicing.
3/4” SAE female
inlet.
3/4" SAE female
outlet.
275 bar max.
The high flow solenoid valve is
designed to control the flow of gas
in a CNG Dispenser.
Between the inlet and outlet, the
valve opens with a differential
pressure of more than 275 bar.
3 x 3/4" SAE
female inlets.
3/4" SAE female
outlet.
275 bar max.
The regulator is a high flow valve,
designed to limit the outlet
pressure of the dispenser.
In the fixed pressure dispenser,
the regulator limits the final fill
pressure to 200 bar.
In the temperature compensating
dispenser, the regulator acts as a
safety device to limit the amount of
over-pressure if the main solenoid
fails to shut off at the correct
pressure.
