Compac C5000 Service Manual

83.
Specifications
Equipment
Item
Compac
Code
Specifications
Description
Three-way
refuelling
valve
RVCI-04
1/4" NPT ports
250 bar max.
The three-way valve is designed
specifically for refuelling CNG
vehicles. The inlet, outlet, and
exhaust ports are designed to be
used as shown in the figure in the
Dispenser Component Location
section. Do not re-pipe the valve in
a different configuration.
Nozzles
7/16" NZ
Probe
1-15 kg/min
1/4" NPT port.
In New Zealand, the probe
complies with NZS 5425.1.
In Australia, the probe complies
with AS/NZS 2739.
OPW CT1000
1-50 kg/min
9/16" SAE inlet
port
200 bar max.
Nozzles allow refuelling for high
pressure NGV applications.
OPW CT5000
1-80 kg/min
7/8" SAE inlet
port
250 bar max.
Nozzles allow refuelling for high
pressure NGV applications.
Inline
breakaways
QBCI-09
1-15 kg/min
9/16" SAE inlet
& outlet ports
Brass inline breakaway with
reconnectable design.
OPW ILB- 1
1-50 kg/min
9/16" SAE inlet
& outlet ports.
250 bar max.
150 to 200 lbs.
(668 to 890 N)
breakaway
force.
Inline breakaway with
reconnectable design. Corrosion-
Resistant with high flow for all
NGV-1 nozzles.
OPW ILB-5
1-80 kg/min
7/8" SAE inlet &
outlet ports.
310 bar max.
150 to 200 lbs.
(668 to 890 N)
breakaway
force.
Inline breakaway with
reconnectable design. Corrosion-
Resistant with high flow quick
fuelling of large storage vehicles.
Isolation
ball valve
Parker 2-way 8 series ball valve
