Product Description 1-5
1.3.1 Left Side Components
The left side external components are shown in Figure 1-2
and are described in Table 1-1.
Figure 1-2.
Left Side Components
Table 1-1
Armada 1700 Computer Components
Left Side
Item Component Function
1
Cable Lock Secures computer to fixed object
2
Speaker/headphone jack Connects stereo speakers, headphone or headset
3
Microphone jack Connects external microphone, disables internal microphone
4
Volume up Increases volume
5
Volume down Decreases volume
6
Left bass reflex speaker port Enhances audio quality
