3-8 Illustrated Parts Catalog
3.6 Miscellaneous Parts
Figure 3-6.
Miscellaneous Parts
Table 3-6
Miscellaneous Parts
Item Description Spares Part Number
1
2
3
4
5
Miscellaneous Plastics kit :
Left clutch/display wiring cover
Right clutch/microphone cover
RTC battery cover
Hard drive cover
Modem cover
316282-001
6 Fan 316271-001
7 Internal AC adapter 316265-001
* Screw kit 316283-001
* Shielding kit (includes RTC battery) 316284-001
* Logo kit 316287-001
* Country kit (N.A.) 316285-001
* Country kit (Europe) 316285-002
* Not illustrated
