Convenience Base C-3
C.3 Convenience Base II Components
The convenience base components are illustrated and described in this section.
Front and Right Side Components
The front and right side convenience base components are shown and identified in this
section.
1 Docking latches
2 Docking alignment pins
3 Docking connector
4 Power switch
5 Security cable lock
6 Docking lever
7 Pass-through AC power outlet
8 Battery charge light
9 Suspend button
: Power/suspend light
; Retaining latches
Figure C-2
. Convenience Base II with RJ45 Front and Right Side Components
