Product Description 1-11
1.3.7 Status Panel Lights
The status panel lights are shown in Figure 1-8 and described in
Table 1-7.
Figure 1-8.
Status Panel Lights
Table 1-7
Armada 1700 Computer Components
Status Panel
Item Component Function
1
Hard drive activity light Indicates hard drive or CD-ROM access
2
MultiBay activity light Indicates MultiBay device activity
3
Number lock indicator Indicates that numbers lock is on
4
Caps lock indicator Indicates that caps lock is on
5
Scroll lock indicator Indicates that scroll lock is on
