Compaq Armada 1700 - Standard and Optional Boards

3-6 Illustrated Parts Catalog
3.4 Standard and Optional Boards
Figure 3-4.
Standard and Optional Boards
Table 3-4
Standard and Optional Boards
Item Description Spares Part Number
1 Memory board (SODIMM), 16-MB, 60 ns, nonparity 313917-001
* Memory board (SODIMM), 32-MB, 60 ns, non parity 313911-001
* Memory board (SODIMM), 64-MB, 60 ns, non parity 313918-001
* Memory board (SODIMM), 128-MB, 60 ns, non parity 310345-001
2 Audio/LED board 316260-001
3 DC-DC voltage converter 316264-001
4 System board with 233-MHz Intel Pentium II CPU 316261-001
* System board with 266-MHz Intel Pentium II CPU 316262-001
5 K56flex modem 316279-001
6 IR module 316313-001
* Not illustrated
