Compaq Armada E500 Series User Manual

Upgrading the Computer 11-5
COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED
Writer: Beth Zanca Saved by: Beth Zanca Saved date: 05/21/99 1:56 PM
Part Number: 131511-001 File name: Ch11.doc
5. Pull away the retention clips
1
on each side of the memory
expansion board to release it. The memory expansion board
tilts toward you.
6. Lift the edge of the memory expansion board
2
and slide it
gently out of the memory expansion slot at a 45-degree angle.
7. Place the memory expansion board in an electrostatic-safe
container.
8. Replace the keyboard.
9. Reconnect external cables and turn on the computer.

Compaq Armada E500 Series Specifications

General

Processor	Intel Pentium III
Chipset	Intel 440BX
Optical Drive	24x CD-ROM or DVD-ROM
Networking	10/100 Ethernet
Wireless	Optional 802.11b
RAM	Up to 512 MB
Display	14.1-inch TFT, 1024x768 resolution
Graphics	ATI Rage Mobility with 8 MB
Ports	USB, Parallel, Serial, VGA, PS/2, Infrared
Battery	Lithium-Ion
Operating System	Windows 98, Windows 2000
Storage	6 GB - 12 GB Hard Disk Drive
Battery Life	Approximately 2-3 hours
