Compaq Armada E500 Series User Manual

Working with Removable Drives and Device Bays 6-7
COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED
Writer: Beth Zanca Saved by: JAbercrombie Saved date: 07/13/99 1:34 PM
Part Number: 131511-001 File name: Ch06.doc
MultiBay Devices
The MultiBay supports a CD-ROM drive, DVD-ROM drive, LS-
120 drive, second hard drive, or a third battery pack.
CAUTION: Some but not all MultiBay devices can be hot plugged.
Refer to "Bay Configuration" in this chapter to determine if the
computer must be on or off before inserting or removing MultiBay
devices. This helps protect the computer or the device from damage
or data loss.
Electrostatic discharge can damage electronic components. Before
touching the hard drive, ensure that you are discharged of static
electricity by touching a grounded metal object.
Inserting a MultiBay Device
1. If your device is not hot-pluggable, turn off the computer.
2. Insert the device into the MultiBay until it locks into place.
IMPORTANT: If installing a second hard drive, insert the hard drive
into a hard drive adapter before installing the drive into the
MultiBay.

Compaq Armada E500 Series Specifications

General

Processor	Intel Pentium III
Chipset	Intel 440BX
Optical Drive	24x CD-ROM or DVD-ROM
Networking	10/100 Ethernet
Wireless	Optional 802.11b
RAM	Up to 512 MB
Display	14.1-inch TFT, 1024x768 resolution
Graphics	ATI Rage Mobility with 8 MB
Ports	USB, Parallel, Serial, VGA, PS/2, Infrared
Battery	Lithium-Ion
Operating System	Windows 98, Windows 2000
Storage	6 GB - 12 GB Hard Disk Drive
Battery Life	Approximately 2-3 hours
