Compaq Armada E500 Series User Manual

Using Battery Packs 4-3
COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED
Writer: Beth Zanca Saved by: JAbercrombie Saved date: 07/13/99 1:05 PM
Part Number: 131511-001 File name: Ch04.doc
NOTE: The battery charge light is the right light on the front edge
of the computer. It turns on (solid) when a battery pack (in the
battery bay, DualBay, or MultiBay) is charging. It turns off when
fully charged. It blinks in a low-battery condition.
When the battery charge light turns off, the battery packs are fully
charged.
Inserting and Removing the Primary Battery
Pack
Removing the Primary Battery Pack
CAUTION: If the battery pack you are about to remove is the only
source of power to the computer, initiate Hibernation or connect the
computer to external power before removing the battery.
1. Pull forward on the primary battery release latch to release the
battery pack.
2. Remove the battery pack from the primary battery bay.

Compaq Armada E500 Series Specifications

General

Processor	Intel Pentium III
Chipset	Intel 440BX
Optical Drive	24x CD-ROM or DVD-ROM
Networking	10/100 Ethernet
Wireless	Optional 802.11b
RAM	Up to 512 MB
Display	14.1-inch TFT, 1024x768 resolution
Graphics	ATI Rage Mobility with 8 MB
Ports	USB, Parallel, Serial, VGA, PS/2, Infrared
Battery	Lithium-Ion
Operating System	Windows 98, Windows 2000
Storage	6 GB - 12 GB Hard Disk Drive
Battery Life	Approximately 2-3 hours
