Compaq Armada E500 Series User Manual

Taking a Look at the Computer 2-7
COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED
Writer: Beth Zanca Saved by: JAbercrombie Saved date: 07/13/99 12:55 PM
Part Number: 131511-001 File name: Ch02.doc
Bottom Components
Bottom Components
Component Function
1
Modem compartment Provides access to the internal
modem. The modem is available on
select models and as an option for
other models.
2
Keyboard security screw Keeps the keyboard secured to the
computer.
3
Hard drive release latch Releases the hard drive.
4
Hard drive compartment Provides access to the primary hard
drive. A security screw prevents
unauthorized access to the hard
drive. Use a standard screwdriver to
remove the screw.
5
Battery release latch Releases the primary battery pack.
6
DualBay release latch Releases the second battery pack or
diskette drive from the DualBay.
7
MultiBay release latch Releases the MultiBay device from
the MultiBay.

Compaq Armada E500 Series Specifications

General

Processor	Intel Pentium III
Chipset	Intel 440BX
Optical Drive	24x CD-ROM or DVD-ROM
Networking	10/100 Ethernet
Wireless	Optional 802.11b
RAM	Up to 512 MB
Display	14.1-inch TFT, 1024x768 resolution
Graphics	ATI Rage Mobility with 8 MB
Ports	USB, Parallel, Serial, VGA, PS/2, Infrared
Battery	Lithium-Ion
Operating System	Windows 98, Windows 2000
Storage	6 GB - 12 GB Hard Disk Drive
Battery Life	Approximately 2-3 hours
