Removing a Memory Expansion Board
1. Shut down and turn off the computer. Disconnect any external
cables.
2. Remove the security screw from the bottom of the
computer.
3. Release the keyboard by successively inserting a paper clip or
similar instrument into the four keyboard releases
1
.
!
WARNING: To reduce the risk of personal injury from hot surfaces,
allow the internal system components to cool before touching them.
4. Lift the keyboard
2
.
!
WARNING: To reduce the risk of electrical shock, fire, or damage to
the equipment, do not turn on the computer or reconnect any
external cables during this procedure.

Compaq Armada E500 Series Specifications

General

Processor	Intel Pentium III
Chipset	Intel 440BX
Optical Drive	24x CD-ROM or DVD-ROM
Networking	10/100 Ethernet
Wireless	Optional 802.11b
RAM	Up to 512 MB
Display	14.1-inch TFT, 1024x768 resolution
Graphics	ATI Rage Mobility with 8 MB
Ports	USB, Parallel, Serial, VGA, PS/2, Infrared
Battery	Lithium-Ion
Operating System	Windows 98, Windows 2000
Storage	6 GB - 12 GB Hard Disk Drive
Battery Life	Approximately 2-3 hours
