Compaq Armada E500 Series User Manual

2-4 Taking a Look at the Computer
COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED
Writer: Beth Zanca Saved by: JAbercrombie Saved date: 07/13/99 12:55 PM
Part Number: 131511-001 File name: Ch02.doc
Right Side Components
Right Side Components
Component Function
1 PC Card slots Slots that support Type II or Type III
PC Cards, such as modem, hard
drive, or network cards. These slots
accept 16-bit PC Cards and 32-bit
Cardbus Cards.
2 Microphone jack Connects to an external microphone.
3 Stereo speaker/
headphone jack
Connects to a headphone or external
speakers.
4 Lock provision Accepts an anti-theft cable that
secures the computer to a fixed
object.
5 RJ-45 jack Connects the Ethernet cable (NIC) to
the computer. Available on models
with an internal NIC/modem
combination
6 RJ-11 jack Connects the RJ-11 modem cable to
the computer. Available on models
with an internal modem
Continued

Compaq Armada E500 Series Specifications

General

Processor	Intel Pentium III
Chipset	Intel 440BX
Optical Drive	24x CD-ROM or DVD-ROM
Networking	10/100 Ethernet
Wireless	Optional 802.11b
RAM	Up to 512 MB
Display	14.1-inch TFT, 1024x768 resolution
Graphics	ATI Rage Mobility with 8 MB
Ports	USB, Parallel, Serial, VGA, PS/2, Infrared
Battery	Lithium-Ion
Operating System	Windows 98, Windows 2000
Storage	6 GB - 12 GB Hard Disk Drive
Battery Life	Approximately 2-3 hours
