Compaq Armada E500 Series User Manual

Using PC Cards 9-3
COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED
Writer: Beth Zanca Saved by: J Abercrombie Saved date: 07/01/99 11:04 AM
Part Number: 131511-001 File name: Ch09.doc
Removing a PC Card
1. If you are running Windows 95 or Windows 98, you must
stop the PC Card before removing it (see “Stopping a
PC Card” later in this chapter). You do not need to turn the
computer off or initiate Suspend. If you are running
Windows NT 4.0, you must close Windows NT 4.0 and turn
off the computer.
CAUTION: Failure to stop a PC Card before removing it may
cause loss of data.
2. To release the PC Card eject button, depress the button
1
once. To eject the PC Card, firmly depress the PC Card eject
button a second time.
3. Remove the card
2
.
NOTE: If you are running Windows 95, the computer beeps twice if
it is turned on when the PC Card is removed.

Compaq Armada E500 Series Specifications

General

Processor	Intel Pentium III
Chipset	Intel 440BX
Optical Drive	24x CD-ROM or DVD-ROM
Networking	10/100 Ethernet
Wireless	Optional 802.11b
RAM	Up to 512 MB
Display	14.1-inch TFT, 1024x768 resolution
Graphics	ATI Rage Mobility with 8 MB
Ports	USB, Parallel, Serial, VGA, PS/2, Infrared
Battery	Lithium-Ion
Operating System	Windows 98, Windows 2000
Storage	6 GB - 12 GB Hard Disk Drive
Battery Life	Approximately 2-3 hours
