Chapter 4 Access to Web-based Interface
12
In Internet Explorer
1. Select the File menu, then select Open.
2. In the Open dialog box, enter the IP address of the Gateway. The default address is
http://192.168.100.128.
3. Click on the OK button.
You will see the following screen appears on the Web browser program. Type in the
password and click Log On! button. The default password is “password”.
After logging in to the Management system, the Main Page will display as shown
below. The image of Compex CGX3224 is shown on the upper right window. The
status of each switch port (i.e. link, speed and duplex mode) can be seen clearly from
the LED displays on the image. The lower right window is used to display the web
pages of versatile configuration and operation.
Command Menu
Window
Configuration
Window
