Chapter 4 Access to Web-based Interface

The Main menu includes four sections in the Command Menu Window, namely

CONFIGURATION, ADVANCED, SYSTEM TOOLS and HELP. The overall

descriptions for individual sub-functions are listed as shown:

CONFIGURATION menu

• Port Configuration – configuration for communications via network

Please refer to Section 5.1 Port Configuration on Page 16

• VLAN Configuration – setup Virtual LAN, whether in tagged or untagged-based

Please refer to Section 5.2 Virtual LAN Configuration on Page 18

• Trunking Configuration – Extend the limitation of bandwidth

Please refer to Section 5.3 Trunk Configuration on Page 19

• DHCP Configuration – setup, reserve or activate DHCP

Please refer to Section 5.4 DHCP Configuration on Page 21

• WAN Configuration – support Static, Dynamic and PPP over Ethernet services

Please refer to Section 5.5 WAN Configuration on Page 25

• NAT Configuration – increase security by preventing unauthorized access through

WAN

Please refer to Chapter 6 NAT Configuration on Page 27

ADVANCED menu

• STP Configuration - discovers and eliminates redundant paths in the network

topology

Please refer to Section 8.1 STP Configuration on Page 39

• IGMP Configuration - allows the device to forward multicast traffic intelligently

Please refer to Section 8.2 IGMP Configuration on Page 44

• Stack Configuration – allows user to enable the stacking function of the switches

Please refer to Section 8.3 Stack Configuration on Page 47

• SNMP Configuration – monitors and oversees network

Please refer to Section 8.4 SNMP Configuration on Page 51

• RMON Statistic – enables various network monitors and console systems to

exchange network-monitoring data

Please refer to Section 8.5 RMON Statistic on Page 52
