Chapter 4 Access to Web-based Interface
14
• Port Security – secures/reserves certain port/s from other user’s access
Please refer to Section 8.6 Port Security on Page 53
• Mirror Port Configuration – duplicates a port's traffic on a port
Please refer to Section 8.7 MirrorPort Configuration on Page 54
• Aging Control – limits the resource in the forwarding table
Please refer to Section 8.8 Aging Control on Page 56
• Address Search – searches for Host and MAC address of the connected device in
the network
Please refer to Section 8.9 Address Search on Page 57
SYSTEM TOOLS menu
• System Clock – manages and utilizes timing based function
Please refer to Section 9.1 Set System Clock on Page 59
• Remote Management - access your Compex CGX3224 through Internet (WAN) or
Local Area Network.
Please refer to Section 9.2 Remote Management on Page 60
• System Configuration – allows change of IP Address, Subnet Mask or Gateway
Please refer to Section 9.3 System Configuration on Page 62
• System Information – indicates essential information of Compex CGX3224
Please refer to Section 9.4 System Information on Page 63
• Change Password – amends system administrator’s password
Please refer to Section 9.5 Change Password on Page 64
• Firmware Upgrade – uploading latest firmware to Compex CGX3224
Please refer to Section 9.6 Upgrading Compex CGX3224 Firmware on Page 65
• Save or Reset Settings – saves or resets all settings
Please refer to Section 9.7 Save or Reset Settings on Page 66
• Message Window – various actions which is taken previously while configuring
can be seen in this window
Please refer to Section 9.8 Message Window on Page 68
• Reboot Switch – restarts the device
Please refer to Section 9.9 Reboot Switch on Page 68
