C-Band Transceiver Revision 1
CSAT-5060 5 to 25 Watt Installation MN/CSAT5060.IOM
A–4
Item No. Part No. Nomenclature QTY
1 FP/BR0095 Bracket, Single-Thread 25W CSAT 1
2 HW/M8X1.25MMHEX Bolt, Hexhead 4
3 HW/M81.25X20MMFHSS Screw, Flathead 4
4 HW/M8FLATSS Washer, Flat SS 4
5 HW.M8SPRINGNUT Springnut 4
6 HW/M8LOCKSS Washer, Splitlock SS 4
Figure A-2. Single-Thread Bracket, AS/0608
