CSAT-5060 C-Band Transceivers Revision 1
Appendix A MN/CSAT5060.IOM
A–11
CSAT Remote Commands
Parameter
Type Command Arguments Description of arguments
Response to
Command Query
Response to
Query
TX Slope Adjust USA= 3 bytes Command or Query.
TX Slope Adjust, between 0.0 and 1.0.
Resolution = 0.1.
Example: USA=0.3
USA= (message ok)
USA? (received ok, but
invalid arg. found)
USA? USA=x.x
See Note 1
RX Slope Mode DSM= 1 byte,
value of 0,1
Command or Query.
RX Slope Mode, where:
0 =Manual Mode,
1 = Calibrated Mode.
Example: DSM=1
DSM=(message ok)
DSM?(received ok, But
invalid argument found)
DSM? DSM=x
See Note 1
RX Slope Adjust DSA= 3 bytes Command or Query.
RX Slope Adjust, between 0.0 and 1.0.
Resolution = 0.1.
Example: DSA=0.3
DSA= (message ok)
DSA? (received ok, but
invalid arg. found)
DSA? DSA=x.x
See Note 1
Reference
Oscillator Adjust
REF= 3 bytes Command or Query.
Ref Osc Adjust, between 000 and 255.
Resolution 001.
Example: REF=087
Note: REF cannot be adjusted when the CSAT
is locked to an external reference source.
REF= (message ok)
REF? (received ok, but
invalid argument found)
REF* (message ok, but
not permitted in current
mode)
REF? REF=xxx
See Note 1
Cold Start CLD= 1 byte,
value of 0,1
Command or Query.
Cold Start, where:
0 = Disabled,
1 = Enabled
Example: CLD=1
CLD= (message ok)
CLD? (received ok, but
invalid arguments
found)
CLD? CLD=x
See Note 1
Auto Fault
Recovery
AFR= 1 byte,
value of 0,1
Command or Query.
Auto Fault Recovery, where:
0 = Disabled,
1 = Enabled
Example: AFR=1
AFR= (message ok)
AFR? (received ok, but
invalid arguments
found)
AFR? AFR=x
See Note 1
Online Status
N/A
1 byte,
value of 0,1
Query Only.
Online status, where:
0 = OFFLINE,
1 = ONLINE
Example: ONL=1
ONL= (message ok)
ONL? (received ok, but
invalid arguments
found)
ONL? ONL=x
See Note 1
