CSAT-5060 C-Band Transceivers Revision 1
Appendix A MN/CSAT5060.IOM
A–12
CSAT Remote Commands
Parameter
Type Command Arguments Description of arguments
Response to
Command Query
Response to
Query
LNA Current
Source
LCS= 1 byte,
value of 0,1
Command or Query.
LNA Current Source, where:
0 = Disabled,
1 = Enabled
Example: LCS=1
LCS= (message ok)
LCS? (received ok, but
invalid arguments
found)
LCS? LCS=x
See Note 1
LNA Fault Logic LFL= 1 byte,
value of 0,1
Command or Query.
LFL controls whether or not the Summary Fault Relay
(SFR)
is affected by the LNA Current window monitor, where:
0 = A LNA Current fault does not effect the SFR,
1 = A LNA Current fault will effect the SFR.
Example: LFL=1
LFL= (message ok)
LFL? (received ok, But
invalid arguments
found)
LFL? LFL=x
See Note 1
Calibrate LNA
Current
CAL= None Command only.
This command is used to set the calibration point for
the LNA current alarm feature.
Example: CAL=
CAL= (message ok)
N/A
N/A
LNA Current
Window
LCW= 2 bytes,
numerical
Command or Query.
LNA Current Monitor Window, this command allows the
user to set the alarm window in ± % of the calibrated LNA
current. Valid inputs are 20 to 50 in increments of 1%. In
addition, setting the value to 99 disables the alarm
function.
Example: LCW=30, set the alarm window at ± 30%.
LCW= (message ok)
LCW? (received ok, but
invalid arguments
found)
LCW? LCW=xx
See Note 1
External
Reference Fault
Logic
XRF= 1 byte,
value of 0,1
Command or Query.
XRF controls whether or not the Software monitors the
external reference source. If enabled and no source is
present a fault will be reported.
0 = Ext Reference not monitored
1 = Ext Reference is monitored and the lock state reported.
Example: XRF=1
XRF= (message ok)
XRF? (received ok, but
invalid arguments
found)
XRF? XRF=x
See Note 1
