CSAT-5060 C-Band Transceivers Revision 1
Appendix A MN/CSAT5060.IOM
A–13
CSAT Remote Commands
Parameter
Type Command Arguments Description of arguments
Response to
Command Query
Response to
Query
CSAT Global
Configuration
CGC= 60 bytes,
with numerical
entries fixed
value entries,
and delimiters
Command or Query. Global configuration of Unit, in the
form: FFFF.FAA.AAMSB.BGG.GGZffff.faa.aamsb.b
gg.ggNRCXOOOLWWDeeeeeee, where:
F = TX Frequency – same as UFQ= (6 bytes)
A = TX Attenuation – same as UAT= (5 bytes)
M = TX Mute – same ad UMU= (1byte)
S = TX Slope Mode – same as USM= (1 byte)
B = TX Slope Value – same as USA= (3 bytes)
G = TX Gain Offset – same as UGO= (5 bytes)
Z = TX Amplifier State – same as AMP= (1 byte)
f = RX Frequency – same as UFQ= (6 bytes)
a = RX Attenuation – same as UAT= (5 bytes)
m = RX Mute – same ad UMU= (1byte)
s = RX Slope Mode – same as USM= (1 byte)
b = RX Slope Value – same as USA= (3 bytes)
g = RX Gain Offset – same as UGO= (5 bytes)
N = Mute Mode – same as MUT= (1 byte)
R = Auto Fault Recovery – same as AFR= (1 byte)
C = Cold Start Mode – same as CLD= (1 byte)
X = Ext Ref Fault Logic – same as XRF= (1 byte)
O = Ref Oscillator Adjust – same as REF= (3 bytes)
L = LNA Current Source – same as LCS= (1 byte)
W = LNA Current Window – same as LCW= (3 bytes)
D = LNA Fualt Logic – same as LFL= (1 byte)
e = expansion (7 bytes), set to ‘0’
Example: CGC=5901.012.75000.3-0.0013652.5
12.75000.3-0.00110108719900000000
CGC= (message ok)
CGC? (received ok,
But invalid arguments
found)
CGC?
CGC= FFFF.FAA.AAMS
B.BGG.GGZffff.faa.aams
b.bgg.ggNRCXOOOLWWDeeeeeee
See Note 1
Redundancy
Controller Box
Auto/Manual Mode
RAM= 1 byte,
value of 0,1
Command or Query.
RAM controls whether or not the Redundancy Controller is
in automatic or manual mode, where:
0 = Manual Mode,
1 = Auto Mode.
Example: RAM=1
Note: Access via the Online unit.
RAM= (message ok)
RAM? (received ok, but
invalid arguments
found)
RAM?
RAM=x
See Note 1
