CSAT-5060 C-Band Transceivers Revision 1
Appendix A MN/CSAT5060.IOM
A–16
CSAT Remote Commands
Parameter
Type Command Arguments Description of arguments
Response to
Command Query
Response to
Query
Retrieve
Configuration
Status
N/A
113 bytes,
alpha numerical
Query only.
Used to Query the configuration status of the CSAT
Example: RCS=’cr’
UFQ=5845.0’cr’
DFQ=3625.0’cr’
UAT=12.50’cr’
DAT=01.50’cr’
ONL=YES’cr’
XMT=ON’cr’
AMP=ON’cr’
UMU=OFF’cr’
RCV=ON’cr’
DMU=OFF’cr’
CLD=OFF’cr’
AFR=ON’cr’
EXT=NO ’cr’’lf’
N/A RCS? RCS=x….x
See Note 2
Retrieve LNA
Status
N/A
23 bytes,
alpha numerical
Query only.
Used to Query the LNA status of the CSAT
Example: RLS=’cr’
LCS=ON’cr’
LCW=40’cr’
LFL=1’cr’’lf’
N/A RLS? RLS=x….x
See Note 2
Retrieve Utility
Status
N/A
32 bytes,
alpha numerical
Query only.
Used to Query the utility status of the CSAT
Example: RUS=’cr’
BDR=9600’cr’
REF=087’cr’
USA=0.3’cr’
DSA=0.4’cr’’lf’
N/A RUS? RUS=x….x
See Note 2
