LPOD C- / Ku-Band Outdoor Amplifier/ Block Up Converter (BUC) Revision 3
Appendix B MN-LPOD
B–12
Parameter Type
Command
(Instruction
Code and
Qualifier)
Arguments for
Command or
Response to
Query
Description of Arguments
(Note that all arguments are printable ASCII
characters)
Response to
Command
(Target to Controller)
Query
(Instruction
Code and
qualifier)
Response to
Query
(Target to
Controller)
Concise
Configuration
Status
N/A 26 bytes Query only.
Used to query the configuration status of the unit. This
is the concise version of the RCS command.
Example:
CCS=aa.aa;b;c;d;e;ff.ff;g;hhh; ’cr’’lf’
Where:
aa.aa = attenuation in dB (ATT)
b = RF power amplifier state, 0 = Off, 1 = On (AMP)
c = mute state, 0 = un-muted, 1 = muted (MUT)
d = online status (ONL)
e = redundancy state and mode (ESW)
ff.ff = Attenuator offset in dB (AOF)
g = auto fault recovery mode (AFR)
hhh = External reference status, N/A = no external
reference, 05M for 5 MHz, and 10M for a 10 MHz (See
Note)
Note: hhh will always be N/A if the internal reference
oscillator option is not installed.
CCS= CCS? CCS=x….x
(See Description
of Arguments for
details)
Concise RF
Power FET
Current Status
N/A Variable length
depending on the
number of FETs
installed in the
amplifier
Query only
Concise version of RFS.
Example: CFS=xxx,xxx,x.x,x.x,……….,x.x,
CFS= CFS? CFS=x…..x
(See description
of RFS. Note that
each argument is
separated by a
comma.)
Circuit
Identification
CID= 48 bytes
Command or Query.
CID is a user-defined string of data that may be used
to identify or name the unit or station. The CID is a 48-
byte field of data that is entered as one line, but it will
be read back from the unit as two 24-byte lines of data.
Examples:
<1/CID= Station #001--SSPA #01--’cr’
>0001/CID=
<1/CID?’cr’
>0001/CID=’cr’
Station #001’cr’
--SSPA #01--’cr’’lf’
Default Value: ------------------------
CID=
CID?
CID*
CID? CID=x…x
(See Description
of Arguments for
details)
To Next Page
