LPOD C- / Ku-Band Outdoor Amplifier/ Block Up Converter (BUC) Revision 3
Appendix B MN-LPOD
B–13
Parameter Type
Command
(Instruction
Code and
Qualifier)
Arguments for
Command or
Response to
Query
Description of Arguments
(Note that all arguments are printable ASCII
characters)
Response to
Command
(Target to Controller)
Query
(Instruction
Code and
qualifier)
Response to
Query
(Target to
Controller)
Calibrate LNB
Current
CLC= none Command or Query.
The CLC command stores the value of the LNB Current
Supply (in mA) as a reference point. The LNB current
alarm point is then determined by the calibrated LNB
reference point, and the LNB current window setting
(see LCW command).
Note: this command will return a mode error if the LNB
current source output has not been enabled first (see
LCS command).
Example: <1/CLC=’cr’
>0001/CLC=’cr’’lf’
The CLC query will return the value that was stored
during the LNB current calibration.
Example: <1/CLC?’cr’
>0001/CLC=xxx.x Where:
xxx.x is the calibrated LNB current value in mA.
Default Value: 000.0
CLC=
CLC?
CLC*
CLC? CLC=xxx.x
(See Description
of Arguments for
details)
Clear Statistics
Log
CSL= 1 byte Command only.
Used to clear the statistics log entries.
Example:
<1/CSL=1’cr’
>0001/CSL=’cr’’lf’
CSL=
CSL?
CSL*
N/A CSL=
Concise Utility
Status
E
N/A 15 bytes
Query only.
Used to Query the Maintenance status of the unit,
response is comma delimited.
Example:
<1/CUS?’cr’
>0001/CUS=aaaa;bbbbb;ccc;’cr’’lf’
Where:
aaaa = Remote Unit Address
bbbbb = Remote Baud Rate
ccc = Reference oscillator tuning voltage DAC value
(See Note)
Note: ccc is only present if a reference oscillator is
installed.
CUS= CUS?
CUS=x….x
(See Description
of Arguments for
details)
