Comtech EF Data LPOD - Page 143

LPOD C- / Ku-Band Outdoor Amplifier/ Block Up Converter (BUC) Revision 3
Appendix B MN-LPOD
B–25
Parameter Type
Command
(Instruction
Code and
Qualifier)
Arguments for
Command or
Response to
Query
Description of Arguments
(Note that all arguments are printable ASCII
characters)
Response to
Command
(Target to Controller)
Query
(Instruction
Code and
qualifier)
Response to
Query
(Target to
Controller)
Reference
Oscillator Tuning
REF= 3 bytes Command or Query.
Adjusts the reference oscillator tuning voltage by
sending a DAC value in the following format: REF=xxx,
where: xxx is a numeric value from 0 to 255, and the
default value is set to 87.
Example: <1/REF=087’cr’
>0001/REF=’cr’’lf’
Note: This command sets the DAC value, but the
actual Reference Oscillator tuning voltage can be
monitored using the RMS command.
Default Value: 087
REF=
REF?
REF*
REF? REF=xxx
(Same format as
command
arguments)
Retrieve
Equipment Type
E
N/A 22 bytes Query only.
The unit returns a string indicating the Model Number
and the version of the M&C firmware installed in the
unit.
Example: <1/RET?’cr’
>0001/RET=CPA-300 VER: 1.0.3’cr’’lf’
RET= RET? RET=x….x
(See Description
of Arguments for
details)
RF Power FET
Current status
N/A variable length
depending on the
number of FETs
installed in the RF
amplifier
Query only.
Used to display all the FET currents.
Example: <1/RFS? ’cr’
>0001/RFS=’cr’
Q01=.xxx’cr’
Q02=.xxx’cr’
Q03=xx.x’cr’
Q04=xx.x’cr’
Q05=xx.x’cr’
Q06=xx.x’cr’
Q07=xx.x’cr’
Q08=xx.x’cr’
Q09=xx.x’cr’
Q10=xx.x’cr’
Q11=xx.x’cr’
Q12=xx.x’cr’
Q13=xx.x’cr’
Q14=xx.x’cr’
Q15=xx.x’cr’
Q16=xx.x’cr’’lf’
Note: If the value is one amp or greater the format is
xx.x, and if the value is less than one amp then the
format is .xxx
RFS= RFS? RFS=x….x
(See Description
of Arguments for
details)
