LPOD C- / Ku-Band Outdoor Amplifier/ Block Up Converter (BUC) Revision 3
Appendix B MN-LPOD
B–24
Parameter Type
Command
(Instruction
Code and
Qualifier)
Arguments for
Command or
Response to
Query
Description of Arguments
(Note that all arguments are printable ASCII
characters)
Response to
Command
(Target to Controller)
Query
(Instruction
Code and
qualifier)
Response to
Query
(Target to
Controller)
Reboot RBT= 1 byte Soft Reboot
1 = Reboot System
RBT =
RBT?
RBT*
N/A RBT=x
(See Description
of Arguments for
details)
Retrieve
Configuration
Status
N/A 45 bytes
Query only.
Used to Query the configuration status of the unit
Examples:
RCS=’cr’
ATT=12.75’cr’
AMP=1’cr’
MUT=1’cr’
ONL=1’cr’
ESW=1’cr’
AOF=00.00’cr’
AFR=1’cr’
XRF=N/A’cr’’lf’ (see Note)
Where:
ATT= attenuation in dB
AMP= RF power amplifier state, 0=OFF, 1=ON
MUT=RF mute state, 0=un-muted, 1=muted
RED=Online status for redundancy
ESW=Redundancy state and mode,
states: 0=OFF, 1=ON Tx only, 2=ON Tx & Rx
AOF=Attenuator Offset in dB
AFR= auto fault recovery, 0=manual, 1=auto
XRF = External reference status, N/A = no external
reference, 05M for 5 MHz, and 10M for a 10 MHz
Note: XRF will always be N/A if the internal reference
oscillator option is not installed.
RCS= RCS?
RCS=x….x
(See Description
of Arguments for
details)
Online Status
RED= 1 byte Command or Query.
Online status (applies only to redundancy), where:
0 = Offline
1 = Online
Note: this command is functionally identical to the ONL
command.
Example: <1/RED=1’cr’
>0001/RED=’cr’’lf’
RED=
RED?
RED*
RED? RED=x
To Next Page
