LPOD C- / Ku-Band Outdoor Amplifier/ Block Up Converter (BUC) Revision 3
Appendix B MN-LPOD
B–23
Parameter Type
Command
(Instruction
Code and
Qualifier)
Arguments for
Command or
Response to
Query
Description of Arguments
(Note that all arguments are printable ASCII
characters)
Response to
Command
(Target to Controller)
Query
(Instruction
Code and
qualifier)
Response to
Query
(Target to
Controller)
Retrieve Alarm
Status
N/A 168 bytes
Query only.
Used to Query the Alarm status of the unit, where:
OK = no fault condition,
FT = faulted,
AL = alarm,
YS = Yes,
NO = No,
MS = masked.
Example:
<1/RAS?’cr’
>0001/RAS=’cr’
P24V1=OK’cr’ +24V power supply
P24V2=OK’cr’ +24V switch pwr supply
LNBVT=OK’cr’ +13/18V LNB power supply
P13VT=OK’cr’ +13.5V power supply
P10V1=OK’cr’ +10V power supply
A10V1=OK’cr’ +10V1 RF supply
A10V2=OK’cr’ +10V2 RF supply
P7V8T=OK’cr’ +7.8V power supply
P5V8T=OK’cr’ +5.8V power supply
P2V5T=OK’cr’ +2.5V power supply
P1V2T=OK’cr’ +1.2V power supply
N5V8T=OK’cr’ -5.8V power supply
FANR1=OK’cr’ Fan 1 speed
FANR2=OK’cr’ Fan 2 speed
ATEMP=OK’cr’ Amplifier temperature
SHTDN=OK’cr’ Over-temp shutdown
IICST=OK’cr’ I2C bus status
FWPWR=OK’cr’ Forward power in dBm
CHKSM=OK’cr’ Flash checksum
FPGAD=OK’cr’ FPGA done status
BUCLD=OK’cr’ BUC lock detect
REFLD=OK’cr’ Reference lock detect
LNBCS=OK’cr’ LNB current status
SWITC=OK’cr’ Waveguide switch position status
RDLNK=OK’cr’ Redundant link status
TRMST=YS’cr’’lf’ Terminal Status
Note: LNBVT, A10V1, A10V2, FANR1, FANR2,
BUCLD, REFLD, LNBCS, SWITC and RDLNK will only
appear in the list if the appropriate model / options
have been selected / installed.
RAS= RAS?
RAS=x….x
(See Description
of Arguments for
details)
