LPOD C- / Ku-Band Outdoor Amplifier/ Block Up Converter (BUC) Revision 3
Appendix B MN-LPOD
B–28
Parameter Type
Command
(Instruction
Code and
Qualifier)
Arguments for
Command or
Response to
Query
Description of Arguments
(Note that all arguments are printable ASCII
characters)
Response to
Command
(Target to Controller)
Query
(Instruction
Code and
qualifier)
Response to
Query
(Target to
Controller)
Retrieve Next 5
unread stored
Statistics
N/A 75 bytes Query only.
Unit returns the oldest 5 Stored Statistics entries which
have not yet been read over the remote control.
Reply format: {CR}Sub-body{CR}Sub-body{CR}Sub-
body{CR}Sub-body{CR}Sub-body, where:
Sub-body=
ddmmyyhhmmssaaa.abbb.bccc.cdd.ddefghhh.hiii.i
ddmmyy = day/month/year
hhmmss = hour:minute:second
aaa.a = Operating Temperature (I.E. +40.0)
bbb.b = Amp Temperature (I.E. +40.0)
ccc.c = RF Power output
dd.dd = Attenuation Setting
e = Amp On/Off
f = Mute On/Off
g = Online/Offline Status
hhh.h = LNB Current (mA)
iii.i = BUC Tuning Voltage
If there are less than 5 entries to be retrieved, the
remaining positions are padded with zeros.
If there are no new entries, the response is RNS*.
RNS= RNS? RNS={CR}Sub-
body{CR}Sub-
body{CR}Sub-
body{CR}Sub-
body{CR}Sub-
body
(See Description
of Arguments for
details)
Serial Number
N/A 9 bytes Query only.
Used to Query the unit’s 9 digit serial number in the
form of RSN=xxxxxxxxx, where: xxxxxxxxx is the unit’s
9-digit serial number.
Example: <1/RSN?’cr’
>0001/RSN=072282040’cr’’lf’
RSN= RSN?
RSN=xxxxxxxxx
(See Description
of Arguments for
details)
Retrieve Utility
Status
N/A 23 bytes,
alpha- numeric
Query only.
Used to Query the utility status of the unit.
Example: <1/RUS=’cr’
>0001/RUS=’cr’
ADR=0001’cr’
BDR=09600’cr’
REF=087’cr’’lf’ (see Note)
Note: REF will only appear if a reference oscillator is
installed.
RUS= RUS?
RUS=x….x
(See Description
of Arguments for
details)
