OptiSorp steam distribution system
TheOptiSorpsteamdistributionsystemisusedinventilationductswhereonlyashorthumidication
distanceisavailable(seechapter5.3.1forcalculationofhumidicationdistance).Ductdimensions
shouldbegivenwhenordering.Pleasenotethefollowingdataforthis:
OptiSorp Number of
steam connections
max. steam
capacity in kg/h
1)
Duct dimension
Width in mm Height in mm
System 1
1 45 (30) 450...2700 450...1650
System 2
2 90 (60) 450...2700 450...2200
1)
For duct width <600 mm the values in parenthesis are valid
Note: Further information on the OptiSorp steam distribution system can be found in the separate in-
stallation and operating instructionssuppliedwiththeproduct.
Fan unit
Thefanunits–incombinationwiththesteamhumidiersCondairMk5Visual–areusedforthedirect
roomhumidication.Theycanbemountedseparately above the unittothewall.
The type of fan unit (FAN3 Mk M BC or FAN3 Mk L BC)andtheamountrequiredisdependentonthe
steamcapacityofthebasicunit(s)andcanbegatheredfromthetableinchapter4.4.1.
Note: Further information on the fan unit can be found in the separate installation and operating instruc-
tionssuppliedwiththeproduct.
Thefanunitsaredeliveredwith:
– Installation accessories including steam hose
– Installation and operating instructions Fan unit
