5 Mounting and installation works
5.1 Safety instructions for mounting and installation works
– Allmountingandinstallationworkmustbeperformedonly by adequately qualied
personnel.Ascertainingthequalicationsisthecustomer‘sresponsibility.
– Alllocalregulationsrelatingtotheexecutionoftherespectiveinstallationwork(Water,
steamandelectricalinstallation)mustbenotedandcompliedwith.
– All the information contained in these installation and operating instructions relating to
equipmentassemblyandtowater,steamandelectricalinstallationmustbeuncondi-
tionallyobservedandcompliedwith.
– Caution - Danger from electric shock! The connection of the steam humidier to
the mains electrical supply must not be made until all installation work has been
completed.
– Electronic components are very sensitive to electrostatic discharges. In order to protect
thesecomponents,duringallinstallationworkwiththeequipmentopened,precautions
mustbetakenagainstdamageduetoelectricaldischarge(ESDprotection).
5.2 Unit tting
5.2.1 Humidier location
Theinstallationsiteofthesteamhumidierdependslargelyonthelocationofthesteamdistribution
pipeorfanunit(seechapter5.3.1and5.3.2),respectively.Toensureproperfunctioningofthesteam
humidierandtoobtainanoptimalefciency,thefollowingpointsmustbeconsideredandobserved
whenchoosingthelocationforthesteamhumidier:
– Installthesteamhumidiersothatthelength of the steam hose is kept as short as possible
(max. 4 m) and that the minimum bend radius (R= 300 mm) and up-slope (20 %) or down-slope
(5 %)ofthesteamhoseisobserved(seechapter5.3.3).
– ThesteamhumidiersCondairMk5aredesignedforwall-mounting.Makesurethattheconstruc-
tion(wall,pillar,oor-mountedconsole,etc.)towhichthehumidiersaretobemounted,offersa
sufcientlyhighload-bearingcapacity(takenoticeoftheweightinformationfoundinthischapter),
and is suitable for the installation.
Warning!Donotmountthesteamhumidierdirectlytotheventilationduct(insufcientsta-
bility).
– ThebackpaneloftheCondairMk5isretainingheatduringoperation(max.surfacetemperatureof
themetalhousingapprox.60-70°C).Makesure,therefore,thattheconstruction(wall,pillar,etc.)
towhichtheunitsaretobemounted,doesnotconsistofheat-sensitivematerial.
– Foroperationinvolvingafanunit,thesteamhumidiermustalwaysbeinstalledlowerthanthefan
unit.
– Installthesteamhumidierinsuchamannerthatitisfreelyaccessiblewithsufcientspaceavail-
ableformaintenancepurposes(refertothefollowingillustrationforminimumdistances).
