3 Product overview
3.1 Unit types
ThesteamhumidiersCondair Mk5 are available in 2 different type series:
– Visual
Fordirectorindirectroomairhumidicationwithstandard requirements for control precision.
– Process
Fordirectorindirectroomairhumidicationinlaboratory and process appli cationswherethere
are increased requirements for control precision.
Basically,thedevicesofbothtypeseriesareofthesameconstructionexceptforthelevelcontroland
electronics.TheVisualunits>10kg/hareequippedwithacombinedcontactor/electroniccontroland
alevelunitwithasingleoat.ToachieveahigherlevelofaccuracytheProcessunitsincludeadedi-
catedelectroniccontrolwithspecialcontrolsoftwareandareequippedwithalevelunitcomprisingtwo
oats.
Theyareavailableinversionssuitableforoperationwithuntreated drinking water (with lime collec-
tor tank)orwithfully demineralized water (without lime collector tank).Allversionsareequipped,
asstandard,withanoperating and display unit,bymeansofwhichthecurrentoperatingparameters
canbereadandtheequipmentconguredforoperation,andanintegrated PI controller. The equip-
mentcanbesuppliedwithvariousotheroptions.
Type overview and type designation
Theunitsofbothtypeseriesareavailableinvariousversionswithdifferent steam capacities and
layout of the power section(heatingvoltage).Thefollowingtableprovidesanoverviewofthevarious
models and their capacity ranges.
Condair Mk5 Visual ..-../Process..-.. Heating voltage
small large double unit large
5 8 10 16 20 24 30 40 50
1)
60
1)
80
1)
max. steam capacity in kg/h
5.0 8.0 10.0 16.0 20.0 24.0 30.0 40.0 50.0 60.0 80.0 400V/3~/50...60Hz
4.6 7.3 9.0 14.6 18.0 21.9 27.0 36.2 45.0 54.0 72.4 220V/3~/50...60Hz
5.1 8.4 10.3 16.7 20.6 25.1 30.6 41.5 51.2 61.2 83.0 415V/3~/50...60Hz
5.1 8.7 10.3
––– ––– ––– ––– –––
––– ––– ––– 240V/1N~/50...60Hz
5.1 8.0 10.0
––– ––– ––– ––– –––
––– ––– ––– 230V/1N~/50...60Hz
3.9 5.8 7.1 11.6 14.3 17.4 21.5 28.8 35.6 43.0 57.6 200V/3~/50...60Hz
1)
Mk5 ... 50 ... Mk5 ... 60 ... Mk5 ... 80 ...
Unit A: 20 kg/h 30 kg/h 40 kg/h
Unit B: 30 kg/h 30 kg/h 40 kg/h
