6.7.3 Replacing unit fuses
Warning Danger of death!Beforereplacingtheunitfusethesteamhumidiermust be switched
off and secured against unintentional reconnection asdescribedinchapter6.3.Takecare
thattheelectricitysupplytothemaincontactorisdisconnected(checkwithvoltagetester).
Warning! Electronic components are very sensitive to electrostatic discharge. To protect these
components,measuresmustbetakenagainstdamagefromelectrostaticdischargewhenreplac-
ingtheunitfuse(ESDprotection).
Theunitfusesmayonlybereplacedbytrainedandqualiedpersonnel.
Important!Iftheunitfuseblowsthisisgenerallyduetoafaultyunitcomponent.Thereforeyoushould
checkthesecomponentsbeforereplacingthefuse(seetablebelow).
Onlyusethecorrecttypeoffuseaccordingtothefollowingtable.
Warning! It is not permitted to use repaired fuses.
Power board (F1..F3, F1...F6 or F1...F9)
Supply module (F2)
Supply module (F1)
Control board (F5)
Fuse Specication Before replacing, check
F1 on supply module
F2 on supply module
6.3 A, slow-acting
1 A, quick-acting
Drainpump(blockedorcoilfaulty)
Inletvalve(blockedorcoilfaulty)
F5 on control board 50 mA, quick-acting Control signal
F1…F3 on power board
(Mk5 Visual/Process 5-.. and 8-..)
F1…F9 on power board
(all other models)
16 A, super quick-acting
20 A, super quick-acting
Heating elements (on short-circuit)
Heating elements (on short-circuit)
6.7.4 Resetting fault indication “Error”
Inordertoreturnthesteamhumidiertooperationafterfaultelimination,thesteamhumidiermustbe
switchedoffforapprox.5secondsandthenswitchedonagain.
