6.6 Maintenance
– All maintenance work must be performed only by adequately qualied and trained
personnel familiar with the dangers involved.Ascertainingthequalicationsisthe
customer‘s responsibility.
– Instructionsanddetailsconcerningthemaintenanceworkmustbeobservedandad-
heredtowithoutfail.
– Only the type of maintenance work outlined inthis documentation must be carried
out.
– UseoriginalCondairsparepartsexclusivelytoreplacedefectiveparts.
– Before maintenance is initiated, the steam humidier must be taken out of op-
eration in accordance with instructions in chapter 6.3 and protected against
unintentional switching on.
6.6.1 Notes on maintenance
Tosafeguardreliableoperation,themaintenanceoftheCondairMk5shouldbedevisedinthreestages.
Adistinctionismadeherebetweenperiodicinspections,smallmaintenanceandextendedmaintenance
ofthesteam-airhumidier.
Theintervalsrequiredbetweensmallmaintenanceandextendedmaintenancedependonthewater
qualityandthequantityofsteamgeneratedandcanbepre-selectedontherotaryswitch“S2”onthe
controlboard(seechapter6.1).Afterexpiryoftheselectedinterval,theyellowLEDashes/lightsand
anappropriatemessagealternateswiththenormaloperationindication.
Note:Werecommendtocarryoutanextendedmaintenanceatleastonceayear,independentlyfrom
the maintenance counter.
The following is an overview of the work that should be undertaken for the three maintenance
stages.
– Periodic inspections
When: 1 per week
Work: • Inspectthewaterandsteaminstallationsforcorrectsealinganddamage.
 • Inspectthedrainlineforsoiling.
 • Inspecttheelectricalinstallationforloosecablesanddamagedcomponents.
 • Inspectthesteam-airhumidierfordamage.
– Small maintenance
When: The yellow LED ashes and the message “sm. maintenance due” appears, alternat-
ingwiththenormaloperationindication.
Work: • Carryouttheperiodicinspectionitems
 • Emptythesteamcylinderandcleanthelimecollectortank.
– Extended maintenance
When: The yellow LED lights and the message “lg. maintenance due” appears, alternating
withthenormaloperationindication.
Work: • Carryouttheperiodicinspectionitems
 • Emptythesteamcylinderandcleanthelimecollectortank.
 • Dismantleandcleanthesteamcylinder
 • Cleantheunitinnerchamber
 • Inspectthecomponentsinsidetheunitfordamage (e.g. heating cable connector
onthesteamcylinder,levelunit,etc.)
sm. maintenance
due
lg. maintenance
due
