5.4 Water installation
Allworkconcerningthewaterinstallationmustbeperformedonly by adequately qualied
personnel(e.g.plumbers).Ascertainingthequalicationsisthecustomer’sresponsibil-
ity.
Please observe all local regulations concerning the installation of appliances to the mains
andwastewatersystems.
Warning - danger of electric shock!Forallinstallationwork,thesteamhumidiermust
be disconnected from the mains supply and secured against unintentional re-con-
nection.
5.4.1 Performing the water installation
Overview water installation
 1 Waterconnection,unionnutG1/2"
 2 Watersupplypipe(min.innerØ:8mm)
3 Water drain Ø40 mm
 4 Drainpipe(min.innerØ:40mm,min.30cmdirectedverticallydownwards)
 5 Pressurereducingvalve(compulsoryforwaterpressures>10bar,buildingside)
 6 Manometer(installationrecommended,buildingside)
 7 Filtervalve(accessory“Z261”)
 8 Funnel(buildingside)
 9 Siphon(min.innerØ:40mm,buildingside)
10 Drainline,buildingside(min.innerØ:40mm)
H
2
O
(1...10 bar)
1
3
2
4
5 6 7
8 9 108 9
min. 30 cm
