Condair Mk5 - Inspecting the Steam Installation

29
Usethefollowingchecklisttoascertainthatthesteaminstallationwasperformedcorrectly:
– Steam distribution pipe
Steamdistributionpipecorrectlypositionedandsecured(screwstightened)?
Aretheoutletoricesatrightanglestotheairowdirection?
– Steam hose
Maximumlengthof4m?
Minimumbendradiusof300mm(100mmwithxedpiping)?
Havetheinstructionsforhosepositioningbeenfollowed?
Steamhose:nosagging(condensatepocket)?
Rigidsteamlines:properlyinsulated?Correctinstallationmaterialused?Minimalinternaldiam-
eter maintained?
Steamhosesecurelyattachedwithclamps?
Heatexpansionduringoperationandshorteningofthehosewithageingtakenintoconsider-
ation?
Has the protective plastic tube around the steam hose been removed?
– Condensatehose
Downslopeofatleast20%?
Siphonexistingandlledwithwater?
Condensatehosecorrectlyxed?
– Steam distribution pipe is mounted less than 300 mm above the top edge of the humidier:
Condensatehoseisleddownwithaminimum slope of 20 %, in the form of a siphon (min. hose
bend radius Ø200 mm), directly into a discharge funnel.
Note: If your unit feeds a number of steam distribution pipes, the individual condensate hoses are to
be led into the discharge funnel.
Important! Beforeputtingtheunitintooperation,thesiphonofthecondensatehosemustbelled
withwater.
5.3.5 Inspecting the steam installation
min. 300 mm
min. 20 %
Ømin. 200 mm
min. 300 mm
min. 20 %
Ømin. 200 mm
