Condair Mk5 - Operation; Unit Configuration and Settings

40
6 Operation
6.1 Unit conguration
Warning - danger of electric shock! Disconnect the steam humidier from the mains
supply(heatingandcontrolvoltage)beforeopeningtheunit.
Warning! Electronic components inside the unit are very susceptible to electrostatic dis-
charges.Fortheprotectionofthesecomponents,measuresmustbetakenduringallinstal-
lationworktopreventdamagecausedbyelectrostaticdischarge(ESD–protection).
All adjusting elements are situated on the control board:
– Rotaryswitch“S1”: draininterval
– Rotaryswitch“S2”: maintenanceinterval
– Rotaryswitch“S3”: controlsignal(seechapter5.5.3)
– Rotaryswitch“S4”: unitsettings
Setting the drain interval (“S1”)
The evaporation process increases the concentration of mineral salts in the steam cylinder. Periodic
ushingfollowedbyrellingoffreshwatercankeeptheconcentrationofmineralsaltsatalowlevel.
Theintervaltimetobeselecteddependsonthequalityofthewaterandthetypeofunit.Itmayhave
tobeadaptedtotheactualcircumstancesduringoperation.Thefollowingmaintenanceintervalscan
be selected.
Position “S1” drain interval
at 100% steam capacity
Unit type Condair Mk5 Visual/Process
5-.. 8-.. 10-.. 16-.. 20-.. 24-.. 30-.. 40-.. 50-.. 60-.. 80-..
0
∞
1 720 min.
2 360 min. VE VE VE VE VE VE VE VE VE VE VE
3 180 min.
4 120 min. X
5 60 min. X X
6 30 min. X
7 20 min. X X
8 10 min. X X X X X
9 5 min.
VE= Settingforfullydemineralizedwater
X= Standard setting
Notes:
– Thestandardsettings(seeprecedingtable)refertoawaterhardnessof210ppm(12°dHor21°fH,
respectively).
– IftheCondairMk5isoperatedwithfullydemineralizedwater,theswitchcanbesetto“2”.
– IftheCondairMk5shallbeoperatedwithsoftenedorpartlysoftenedwater,pleasecontactyour
supplier.
– Ifnohumidicationtakesplaceformorethan4hours,theunitwillproceedtoaushingcycleand
aoattestuponthenexthumidicationrequest.
