Setting the maintenance interval (“S2”)
Themaintenanceintervalforthesmallandtheextendedmaintenanceissetwithswitch“S2”.When
thesettimehasexpired,amaintenancemessageindicatesthattheunitshouldbeserviced.
Theintervalstobeselecteddependonthequalityofthewaterandthetypeofunit.Itmayhaveto
beadaptedtotheactualcircumstancesduringoperation.Thefollowingmaintenanceintervalscanbe
selected:
Position
“S2”
Interval for
Unit type Condair Mk5 Visual/Process
small maintenance extend. maintenance 5-.. 8-.. 10-.. 16-.. 20-.. 24-.. 30-.. 40-.. 50-.. 60-.. 80-..
0 200 h 600 h
1 300 h 600 h
2 300 h 900 h
3 450 h 900 h
4 400 h 1200 h X X
5 600 h 1200 h X X X X X
6 500 h 1500 h X X X
7 750 h 1500 h X
8 3000 h 3000 h VE VE VE VE VE VE VE VE VE VE VE
9 6000 h 6000 h
VE= Settingforfullydemineralizedwater
X= Standardsettingforwaterwithmediumhardness(12°dH,21°fH,210ppm)
Note: The maintenance interval times refer to a steam output of 100 %. If less output is required in
operation, the maintenance intervals are correspondingly increased. However,werecommendtocarry
outanextendedmaintenanceatleastonceayear.
Setting the control signal (“S3”)
See informations in chapter 5.5.3
Unit settings (“S4”)
VariousunitparameterscanbesetattheDIPswitch“S4”.Theunitparametersarepresetatthefactory
andmustonlybechangedbythecustomerinconsultationwiththesupplier.
Switch Standard setting Description
1 OFF Automatic temperature stabilization ON/OFF
When the automatic temperature stabilization is switched on, the water in the
steamcylinderismaintainedataspecictemperaturewhenthereisabreak
in steam production, so that steam can be immediately generated again on
renewed demand.
2 OFF Switch pause control ON/OFF
In the “OFF” position the switching element’s pause (Triac and Contactors) is
controlled normally (maintaining “Flicker”-regulations). In the “ON” position the
pauseisreducedtooptimizetheprecisionofcontrol.
3 OFF On/offswitchdelayheatingcontactorON/OFF
Inthe“OFF”positiontheon/offswitchdelayissetforoptimallifeofthecon-
tactors.Inthe“ON”positiontheon/offswitchdelayisreducedtooptimizethe
precisionofcontrol(reducedlifeofheatingcontactors).
4 OFF Spare
