Condair Mk5 - Dimensions and Weights

21
Dimensions and Weights
Minimum distances to observe
437 mm 500 mm
1087 mm
1087 mm
392 mm 594 mm
160 mm257 mm 194 mm212 mm
300 mm 300 mm
69 mm 132 mm 103 mm45 mm
min. 400 mm
min. 600 mm
min. 50 mm
min. 400 mm
min. 600 mm
50 mm
min. 600 mm
Mk5 ...50.. Mk5 ...60.. Mk5 ...80..
Unit A:
20 kg/h 30 kg/h 40 kg/h
Unit B:
30 kg/h 40 kg/h 40 kg/h
Unit A
Unit B
Housing size small large double unit large
Steam capacity
in kg/h
5 8 10 16 20 24 30 40 50 60 80
Netweight
in kg
36 36 37 38 41 43 43 44
1x41
1x43
2x43 2x44
Grossweight
in kg
51 51 52 53 71 73 73 74
1x71
1x73
2x73 2x74
